Tinned Stranded Copper Wires 18 AWG FEP Hook Up Wire
Product Description
Application:
FEP Hook Up Wire has excellent corrosion resistance, oil resistance, strong acid resistance, strong alkali resistance, strong oxidant, etc. Excellent electrical insulation performance, high voltage resistance, high frequency loss, no moisture absorption, insulation resistance; Excellent fire resistance, aging resistance, long service life.
Electronic industry,FEP Hook Up Wirescan be used for temperature compensation wire, low temperature wire, high temperature heating wire, aging wire and flame retardant wire; In the household electric appliance industry, it can be used for the internal wiring of air conditioner, microwave oven, electronic disinfection cabinet, electric rice bun, electronic hot water bottle, electric heater, electric oven, electric frying pan, lamps and lanterns, etc.
Used for Home appliances, Temperature sensors, Lighting lamps (cold light source), Small motors, electromagnetic coils, Automotive interior cables, Electronic appliance, etc.
Product features:
Wear resistant, scratch resistant, easy to rip off, high and low temperature resistant, anti-aging, corrosion resistant, anti-interference
Tin Plated Copper Core FEP Insulation Install Wire
AFP-200
Tin Plated or Silver Plated Copper Core FEP Insulation Shield Install Wire
AFS-200
Tin Plated or Silver Plated Copper Core FEP Insulation Stranded Install Wire
AFSP-200
Tin Plated or Silver Plated Copper Core FEP Insulation Stranded Shield Install Wire
Cable structures and specification:
Wire gauge
Cross-section area
Conductor structure
Max. OD of cable
AF-200 AF-200-1
AFP-200
AWG
mm2
mm
250V
600V
250V
600V
36AWG
0.013mm2
7/0.05
0.65
0.85
1.1
1.3
32AWG
0.035mm2
7/0.08
0.75
0.95
1.2
1.4
30AWG
0.05mm2
7/0.10
0.85
1.05
1.35
1.6
28AWG
0.07mm2
7/0.12
0.9
1.1
1.4
1.65
-
0.1mm2
7/0.14
1
1.2
1.55
1.75
26AWG
0.14mm2
7/0.16
1.1
1.3
1.65
1.95
24AWG
0.2mm2
19/0.12
1.2
1.4
1.75
1.98
-
0.3mm2
7/0.23
1.25
1.48
1.8
2.05
22AWG
0.35/0.40mm2
19/0.16
1.4
1.6
1.95
2.2
20AWG
0.5mm2
19/0.18
1.6
1.8
2.2
2.4
-
0.6mm2
19/0.20
1.75
1.98
2.3
2.5
-
0.75/0.80mm2
19/0.23
1.8
2.1
2.4
2.6
18AWG
1mm2
19/0.26
2
2.2
2.6
2.9
16AWG
1.2mm2
19/0.28
2.2
2.4
2.8
3.1
-
1.5mm2
19/0.32
2.4
2.6
3.1
3.3
14AWG
2mm2
19/0.37
2.7
2.9
3.4
3.6
-
2.5mm2
37/0.30
3.4
3.6
4.2
4.4
12AWG
3mm2
37/0.32
3.6
3.8
4.4
4.6
-
4mm2
37/0.37
4
4.2
4.8
5.1
10AWG
5mm2
37/0.41
4.5
4.7
5.3
5.6
-
6mm2
37/0.45
4.8
5
5.7
5.9
8AWG
8mm2
133/0.28
6
6.5
6.8
7.3
Noted:FEP high temperature lead wire specification and core no. are not limited to above regulation,they could be customized.
Company Informations
1.Production line:9 line
2.Month production capacity:90000m
3.Annual production capacity:RMB20million
4.Advanced electrical,chemical and mechanical properties test equipment for Silver plated cable
EXHIBITION & VISIT
Exhibition:
In the past years,We participated in the Middle East Electricity Exhibition in Dubai,China-ASEAN Exposition,Power-Gen India...
CERTIFICATON
Our Honors:
1. Xiangtan Shenzhou Special Cable Co., Ltd Take the task of China manned space flight project develpment, construction and replated cooperation for Shenzhou 7 manned space flight completed success.
2. Xiangtan Shenzhou Special Cable Co., Ltd carried out the project China manned space project development, construction and test task, for first manned flight task complete success.
3. China Academy of Launch Vehicle Technology Institution: The "Arrow of God" project for the first time China's astronaut taking the outer space exploration.
PACKING & SHIPPING
Shipping:
We use fast international express delivery, such as DHL, UPS, FEDEX, TNT, EMS, etc. We can also send by air, sea, or land transportation as your requrement.
